GSM Elder Caring Burglar Security Alarm Home Water/Gas/Smoke Leakage Detector PIR and Door Sensor SOS Panic Button K4F

Cheap GSM Elder Caring Burglar Security Alarm Home Water/Gas/Smoke Leakage Detector PIR and Door Sensor SOS Panic Button K4F

Cheap GSM Elder Caring Burglar Security Alarm Home Water/Gas/Smoke Leakage Detector PIR and Door Sensor SOS Panic Button K4F

Product ID : 32500708754
Price : $95.13
Discount Price : $86.57

VISIT WEBSITE NOW

Item specifics
  • Power:
    DC12V/1A
  • Zone Number:
    16
  • Video Interface:
    No
  • Model Number:
    K4F
  • Communication Interface:
    Wireless
  • Password Keyboard:
    Yes
  • Kit Configuration:
    Door/Window Sensor
  • Size:
    130*130*27 mm
  • Display:
    Yes
  • Arming Type:
    Password Keyboard
  • Brand Name:
    KING PIGEON
  • Output Number:
    6
  • Alarm Type:
    The Alarm
  • Item Name:
    K4 GSM Elder Caring Alarm System
  • Main Function:
    Temperature Detect and SOS Alarm
  • GSM Frequency:
    850/900/1800/1900 MH
  • Wireless frequency:
    433.92 MHz
  • Wireless Zones:
    16
  • Wired Zone:
    1
  • Application:
    House Security Alarm and Temperature Alarm
  • LCD display:
    current time, which detector activated, indoor current temperature
  • Kit Configuration:
    PIR-100A/DM-100/EM-70/SM-100/WL-100/GL-100A
Product Description


Fast DHL GSM Elder Caring Burglar Security Alarm Home Water/Gas/Smoke Leakage Detector PIR and Door Sensor SOS Panic Button K4F



How to choose and use an alarm system

Now there are so many kinds of home alarm system products in the market that you may not know how to choose the most suitable.

Here we have some suggestions about how to choose and use an alarm system for you.



1. Knowing whether you need a wired system or a wireless one. Normally we recommend wireless system because it is much easier for

you to install.

2. Knowing a complete alarm system not only includes the common burglar alarm, but also includes fire alarm(smoke alarm), panic alarm,

and environmental Alarm.

3. Count the number of doors and windows of your house which a burglar may access. Your alarm system should cover all the entrances

in your house.

4.If you are pet owner, we recommend you to use pet friendly PIR motion sensor to immunity your pet. Because pet can even trigger a

false alarm.

5.Decide if you need Smoke Sensor,Gas sensor,Wireless Flash Siren to beef up your alarm system.

6.Find a proper place to install the alarm panel.

7.IF you have problem of installtion after reading user manual,it is better to ask for help rather than a faulty installation.

8.The first step in eliminating false alarms is to find out what is causing them(the cause for it), such as faulty installation, loose door/window

contacts, low batteries or some other equipment issues.

9.Whether you are leaving your house for a few short minutes, working from home during the day or vacationing on the other side of the world,

your alarm system should be armed and ready to alert you at all time.



K4 Alarm System
Introduction

The K4 GSM Alarm and  SOS Call equips LCD, supports temperature high/low alert, it is not only an alarm system,but also a senior telecare system.



When it used as a GSM Alarm system, the user can call in to Arm/Stay operation with a free charge from its phone. and plus different wireless detectors to protect its assets.

The LCD can display the current time, what sensor activated, and current indoor temperature.

When it used as the senior telecare system, it can be used as a GSM Emergency call system, and also can dial and send SMS to preset numbers while Fall Down, Push SOS Button, Hasn't got up bed in time, carbon monoxide leak, or intrusion.

At this period, the aging trend is very serious in all countries, and lots of seniors living alone. They are need urgently help in sometime,also worry about death while sleep or fall down and nobody know it.



Features

Brevity,Fashion,Neat design;

LCD display current time, which detector activated, indoor current temperature;

Supports temperature higher or lower than preset value alert function(function as a GSM temperature alarm);

Big SOS Button easy to push it;

High quality of voice communication;

Supports 6 preset call numbers for SMS or Call or both;

Supports monitoring senior get up bed in time or not;

Supports wireless fall down detector;

Supports total 16 wireless detectors or SOS buttons;

Supports free charge to Arm/Stay operation;

Inbuilt rechargeable battery inside;

Easy to use, no need to train;

Easy to installation, can put on desk or onto wall.





GSM Main Panel:
Rated Voltage: 12VDC

GSM Frequency: 850/900/1800/1900 MHz

Wireless frequency: 433.92 MHz

Wireless Zones: 16

Backup battery:3.7V/900 mAh

Size: 130*130*27 mm



Water Leakage Detector



Working Voltage: 9-12VDC

Battery Life: About 2 years (counted at 3 times each day)

Wireless Frequency : 433 MHZ

Transmission Range: 100m

Working Current (mA): 10-20mA

Static Current(uA): 4-6uA

Operating temperature: -10degree – +50degree

Relative humidity:  <95% ;

Applications: For indoor use. Kitchen, Coal mine, Corridor, Office, Room, Museum, Library, Finance Room, Warehouse, etc.



Smoke Detector

Working Voltage: 9-12VDC

Battery Life: About 1 year (counted at 3 times each day)

Wireless Frequency : 433 MHz

Transmission Range: 100m

Working Current (mA): 10-30

Static Current(uA): 10

Smoke sensitivity: in accordance with UL Standard 217

Operating temperature: -10degree – +50degree

Relative humidity:  <95%

Size: (R * H) 107 * 36mm



Gas Leakage Detector





Operating Voltage: DC12V-24V

Standby Current: [email protected] ; [email protected]

Alarm Current: [email protected] ; [email protected]

RF Immunity: > 20 V/m 10 – 1000 MHz

Alarm Sensitivity: 10%+/-5 LEL

White Light Immunity: > 8000 lux

Noise(Vp-p): <200mV, (mVp-p)(25 degrees)

Alarm Output: NC or NO, sound & flash alarm

Temperature Range: -10 to +50 degrees

Installation Mode: Wall Mounted

Housing: High-impact ABS

Applications: For indoor use



PIR Motion Sensor

Operating Voltage:  9V Laminated Battery

Detection Range:  V
ertical angle 60degree, Horizontal angle 110 degree, 12m
Standby Current:
less than 25uA
Alarm Current:
less than 22mA
RF Immunity: >
20 V/m 10 – 1000 MHz
Sensitivity: >
3300V/W
Noise(Vp-p): <
200mV, (mVp-p)(25 degrees)
Transmitting Freq.:
433.92MHz
Transmitting Distance:
minimum 100m( in the open area)
Temperature Range:
-10 to +50 degress
Relative Humidity:
90% (25 degress )
Installation Mode:
Wall mounted by bracket
Installation Height:
2m
Housing:
High-impact ABS
Applications:
For indoor use. Corridor, Office, Room, Museum, Library, Finance Room, Warehouse, etc.

Door/Windows Contact Sensor




Working Voltage:
12VDC;
Battery Life: about 1 year (counted at 3 times each day);
Wireless Frequency : 433 MHZ
Transmission Range: 100m
Working Current (mA): 8-20
Static Current(uA): 3
Size: 71*36*15mm
Applications: Doors, windows,etc


SOS Panic Button

Working Voltage: 12V/27A

Battery Life: about 1 year (counted at 3 times each day)

Wireless Frequency : 433.92 MHZ

Communication: Learning code

Transmission Range: 60-100m in open area

Working Current (mA): 8-20

Static Current(uA): 3

Dimensions:31*42*13mm

Wristband: 19cm

Weight: 50g


Flash Siren
Working Voltage
: 9VDC
Sound Volume:
 110dB in 10 Feet

Package Contents:
K4 GSM Main Panel 2G*1
PIR Motion Sensor PIR-100B*2(No battery)
Door/Windows Contact Sensor DM-100C*2(No battery)
SOS Panic Button EM-70*1
Water Leakage Detector WL-100*1
(No battery)
Smoke Detector SM-100*1
(No battery)
Gas Leakage Dtector GL-100A *1
Wired Siren SR-01*1
AC/DC Adapter*1
User Manual *1

If need user manual or APP first, please contact us!

Other Related GSM Alarm System







Packaging Details
  • Unit Type:
    piece
  • Package Weight:
    1.0kg (2.20lb.)
  • Package Size:
    35cm x 32cm x 28cm (13.78in x 12.60in x 11.02in)
