Big Sale HD Portable TV 12 Inch Digital And Analog Led Televisions Support TF Card USB Audio Car Television HDMI Input DVB-T DVB-T2 AC3

Big Sale HD Portable TV 12 Inch Digital And Analog Led Televisions Support TF Card USB Audio Car Television  HDMI Input DVB-T DVB-T2 AC3

Big Sale HD Portable TV 12 Inch Digital And Analog Led Televisions Support TF Card USB Audio Car Television HDMI Input DVB-T DVB-T2 AC3

Product ID : 32871695636
Price : $125.38 – 130.13
Discount Price : $105.32 – 109.31

VISIT WEBSITE NOW

Item specifics
  • Weight(With Package):
    1.4KG
  • Receiving System:
    NTSC,SECAM,PAL
  • Size(With Package):
    34cm*22cm*10
  • DVD Support:
    No
  • SD Card Support:
    No
  • EVD Support:
    No
  • Resolution:
    WXGA(1280*768)
  • Interface Type:
    Composite A/V,USB
  • Brand Name:
    LEADSTAR
  • Screen Size:
    9.1-12inches
  • Battery Support:
    Yes
  • Weight:
    0.7.5KG
  • Size:
    308mm*198mm*25mm
  • Aspect Ratio:
    16:9
  • 3D support:
    Yes
  • Speaker Support:
    Yes
  • Plug Type:
    EU Plug
  • Refresh Rate:
    Ntsc(60Hz)
  • TF Card Support:
    Yes
  • Screen Size:
    11.6 inch
  • Remote Control:
    Yes
  • Use:
    Home Theatre, Portable Audio Player, Mobile Phone, Computer
  • Speaker Type:
    Center
  • Audio Classification:
    Sound Card
  • Type:
    Passive
  • Loudspeaker Accommodation Mode:
    Button
  • Support digital system:
    DVB-T DVB-T2
  • HD TV:
    Yes
Product Description



LEADSTAR HD TV 11.6 Inch Digital Television And Analog TV Receiver And  TF Card And USB Audio And Video Playback Portable DVB-T2 Support the Dolby sound (AC3)



      Digital TV and Analog TV TWO in ONE

ZLSD-D12-a01r



  DTV  = Receive Digital TV (DVB-T or DVB-T2) Support the Dolby sound (AC3)
  ATV

Receive Analog TV (PAL NTSC SECAM) (D / K I B / G M)



Features:
1. Full Compliance with DVBT2,Compactable with DVBT.
2. With analog TV also, DTV+ATV all in 1 TV.
3. 12V input desigh for car, solar energy using.
4. Built-in Battery for portable use.
5. With USB jack,TF card slot, play the content of U-flash drive, support 1080P video, MKV, MOV, AVI, WMV, MPEG1-4, MP4, FLV, MP3, video, high birate decode.
6. 110V~240V universal power supply,DC input low to 12V with more safety.
7. Equipped with high-capacity rechargeable lithium batteries for outdoor using.
8. High sensitivity tuner,strengthens the signal receptivity.
9. DTV support HD TV program recorde to USB flash or Hard disk–(PVR)funtion.
10.Built in battery: 1200MAH *2=7.4V(1200MAH)




This TV supports the reception of the national digital TV   DVB-T   and DVB-T2

DVB-T

Russia,Spain,Franch,Germany,Poland,Turkey,Norway,Ireland, Portugal
     Saudis,Iran,Kazakhstan,Uzbekistan,Burma,Vietnam, Australia . etc

DVB-T2

Russia, Sweden, Finland, England, Columbia,

 India,Indonesia . etc


 World Wide Digital TV Standards (for your reference)
World-TV-SYS

Please note this tv can not receive digital tv signal on below countries,but support the analgo tv signal by our item on these countries:

Janpan    is   ISDB-T
Brazil       is   ISDB-T
Chile        is   ISDB-T
Korea      is   ATSC, T-DMB
America   is   ATSC,ATSC M/H




  Please note! Confirm local digital television system.

If you have questions, please ask the seller (we will respond promptly) Thank you.



21-Detailed-description

Actual measurement size (error 1-2mm)



LSD-D12-14

  11.6 inch digital TV appearance size: 308mm*198mm*25mm







LSD-D12-a08

Boot screen





LSD-D12-a07


    Mode Menu on USB and TF CARD








LSD-D12-a056

Main specification 11.6 inch 12V DVB-T2 Portable TV English And Russian Menu.





Menu of all languages (15 Multi-language menu)

DVB-lx-(33)-850

System main menu

Menu of all languages (15 Multi-language menu)





LSD-D12-a05

Input selection menu

1)   DTV …… Receive digital TV (DVB-T2 or DVB-T) Support the Dolby sound (AC3)

2)   ATV …… Receive analog TV (PAL, NTSC, SECAM)

3)   AV   …… Audio and video input (can be connected to the set-top box or DVD, etc.)

4)   PC    …… VGA input (can be connected to the computer to do the display)

5)   HDMI ……HDMI input (can connect a variety of high-definition input device)

6)   USB…… Play USB disk audio and video files.

7)   CARD….Play TF card audio and video files.





a10

    Russian Menu



Can be connect with the power adapter or the car charger for charging (continuous play)







12V Car Cigar Lighter Charger (Adaptor)



820-DVB-D1010-12V



  • Line length………………….120CM
  • Input…………………………..12V Car Cigarette Lighter
  • Output Current……………..2A
  • Output DC Plug………….. Diameter 5.5mm*2.1mm(internal diameter)



LSD-D12-a04

Left side (input interface)                                                                            Right side (key)









·

LSD-D12-15



LSD-D12-16

There is a screw hole diameter of 6mm behind the TV

you can use it to fix it in the car, or fix it to other places.







  2.5 CM thin design, through continuous improvement, the thickness of this HD player improve than the other brands on the market the video machine reduced the thickness of 1 CM, it is more convenient to carry out for use!



1.VOLUME
2.VOLUME –
3.CHANNEL +
4.CHANNEL –
5.MENU
6.MODE SWITCH
7.LAST
8.NEXT
9.FAST FORWARD
10.FAST REVERSE
11.PALY/ PAUSE
12.ENTER / OK
13.POWER IN

A. ANTENNA INTERFACE
B. VGA PORT
C. AV INPUT
D. AV OUTPUT
E. HEADPHONE
F. HDMI PORT
G. USB PORT
H. POWER IN
I. ON/ OFF



24-Shipping-list

Shipping list:

(1) 11.6 inch DVB-T2
(2) Power adapter   (Charger) (Input AC100-AC240V)
(3) Small antenna    (Test Use )
(4) Audio and video line (AV Line)
(5) Remote control (English)
(6)12V car charger


LSD-D12-a15



                                    All of the goods will be checked before shipment.

                       Add the foam to proctection product to make the transport safety.
​
                                   Purchase the transport insurance for each parcel.


  Please note! Confirm local digital television system.

If you have questions, please ask the seller (we will respond promptly) Thank you.


25-special-note


Special Note:

Television requires a good signal (the international standard 55 db -85 dB), can receive a clear image. Under normal circumstances 🙁 surrounding environment is very large. Tall buildings, mountains and so will seriously affect the spread of television signals)

  1.  Recommend the use of closed-circuit television signal
  2.  Distance television transmitters 0.5 KM-3 KM. Requires good indoor antenna.
  3.  Distance television transmitters 1 KM-10 KM. Need good outdoor antenna.
  4.  Or more away from television transmitters 5 KM. Bad reception environment. Need to have the amplifier outdoor antenna









Factory-01

Factory-02






Packaging Details
  • Unit Type:
    piece
  • Package Weight:
    1.4kg (3.09lb.)
  • Package Size:
    34cm x 22cm x 10cm (13.39in x 8.66in x 3.94in)
